Nissan RB Type B Turbo Manifold

Description

In our opinion, one of the best sounding 6 cylinder engines available. It is also one of the favorites for tuning. Our Nissan RB Turbo Manifold fits the RB20, RB25 and RB26 engines. RB30 fitment is available on request.

There's no shortage of Nissan RB Turbo Manifolds available. What sets the Walton Motorsport version apart from the competition is our construction methods.

Type A or B?

Our long-standing traditional RB Manifold is the type A, this is a compact design with tuned primary pipe lengths to produce a quick spooling setup, however, the size of the turbo is limited to that of a G35 frame, for those of you looking for a larger turbo such as Borg Warner EFR, S300 Series or G-Series above G35 then the further forward-mounted Type B is for you. If you also want/need to run a 60mm Wastegate with ABS then the Type B is also for you. It requires relocating the power steering tank. Both Manifolds are compatible with Air Conditioning requiring minor tweaks to the lines.

Lifetime Warranty

Walton Motorsport has designed their manifolds to put up with some serious abuse though. They offer a lifetime warranty on our products as many do. However, they put a huge emphasis on the strength and durability of our products to stop them from failing. The biggest inconvenience when it comes to a failed manifold (providing none of it ends up inside your turbo or engine) is removing it for repair. By eliminating the failure in the first place, they can honestly say it would be extremely unlikely to experience a failure of our products. Consequently, They wouldn't sleep well at night if our product failed and cost you a result.

Nissan RB Turbo Manifold (RB20 RB25 RB26) Features

• Carefully selected 304 Stainless steel tube. Working to eliminate the risk of material failure.
• Fully Purged welded. Subsequently improving gas flow leading to increases in power and lowered response times.
• Ported Merge Collector Welded Internally and Externally. Resulting in high strength, durability and turbo lifespan.
• Curved wastegate port design developed with leading engine tuners to allow high control and remove boost creep.
• Fully Smoothed Head Ports designed to optimize gas flow. As a result, providing an increase in power and lowered response times.
• Optimized for use with Turbosmart Wastegates 50-60mm.
• Lifetime Warranty against manufacturing faults and defects.
